Baader Medium Levelling Flange BMP for GM 1000 – Steel 106 mm

Support GM1000 HPS

New product

Baader Medium Levelling Flange BMP for GM 1000 – Steel 106 mm

Corrects uneven surfaces or axis misalignment of your pillar with precision. Compatible with GM 1000. Built from solid steel, this BMP flange maintains maximum mount stability while allowing accurate alignment adjustments.

More details

In stock at the supplier. Please contact us for more information.

389.00 CHF tax incl.

More info

Baader Medium Levelling Flange BMP for GM 1000 – Steel 106 mm

DESCRIPTION

The Baader BMP levelling flange for GM 1000 (ref. 2451187) is a robust and precisely machined steel adapter designed to compensate for surface irregularities or imperfect north-south alignment of a concrete pillar. It consists of two solid steel plates joined by six tension rods, allowing for fine levelling adjustments without altering the structural integrity of the base. The upper plate is precision-milled and tapped to directly accept the 10Micron GM 1000 base. Its compact 106 mm height ensures a low profile while maintaining total rigidity.

TECHNICAL SPECIFICATIONS

  • Product reference: 2451187

  • Manufacturer: Baader Planetarium

  • Material: Steel

  • Height: 106 mm

  • Net weight: 9 kg

  • Compatibility: 10Micron GM 1000 mounts

  • Type: Levelling flange for pillar or concrete base
